ky 4 pin VW Male MAP sensor electrical connector waterproof auto plug connector

Short Description:

  • Categories:Hot connectors
  • MOQ:
  • OEM Number:
  • KY Number:
  • Brand:kangyuan
  • Terms of Payment:Western Union,T/T Paypal
  • Delivery Time:7 Wording Days

Product Detail

Product Tags

Quick Details

Place of Origin: Zhejiang, China
Brand Name: KY
Model Number: DJK7045B-1.5-11
Type: Automotive
Application: Automotive, automotive ignition coil or Temperature Sensor
Gender: Female, Male
Color: Black
Housing Material: PBT+GF 20%
Number of Pin: 4 pole one row
Car type: VW,Audi ,Seat, Skoda
Hole size: 1.5mm


Supply Ability

Supply Ability: 100000 Piece/Pieces per Month


Packaging & Delivery

Packaging Details 200pcs/bag, carton boxes
PortNINGBO/SHANGHAI
Lead Time : within 10days after order confirmed


ky 4 pin VW Male MAP sensor electrical connector waterproof auto plug connector

Product Description

Features:

Part No: DJK7045B-1.5-11

1) Material: PA66/PBT, or we can do according to customers’ special requirement.

2) Processing: injection method.

3) Management system:ISO9000

4) OEM allowed.

5) Wire harness available.

we have 1 hole, 2 holes, 3 holes, 4 holes, 5 holes, 6 holes, 8 holes,10 holes,12 holes.

Part number

Mating number

Material

Holes

1K0973804

1J0973704

PBT+GF20%

4 pole connector,1 row,1.5mm JMT pins+s

The sealed connector housings are used for electrical connections between the harness and the various components in the car. In addition to the radial lip seal the male connector housing features a vertical sealing ring. This sealing ring dampens vertical vibrations and thus helps to prevend corrosion. They are adequate for underhood applications or applications in splash water zones. Depending on the series terminals with size 1.5 mm, 3.5 mm and 6.3 mm can be used with the housings.

We offer all items to set up the complete connection system including different sized terminal and cavities and gender.

Send us the used cable range, cable insulation range, cavities and needed quantity as well as the delivery adress. We will appreciate to quote.

Pins in one row. Pin JMT-FEMALE. One wire sealing (QUAD-SEAL-1), can be used with the bigger body seals. Available complete set with pins and seals. Used with sensors and actuators.

Pin size 1,5 mm = Junior Mini Timer

We are able to supply various types of connectors according to clients’ specific requirment. We have already made many new moulds for custoemrs from Italy, Turkey, Austrilia, USA, Poland, Germany…

We’re sincerely looking forward to your contacts, and always be ready to offer our qualified prodcuts with favorable price!

ky 4 pin vw male mapsensor electrical connector waterproof auto plug connector 3

ky 4 pin vw male mapsensor electrical connector waterproof auto plug connector 4

ky 4 pin vw male mapsensor electrical connector waterproof auto plug connector 5

ky 4 pin vw male mapsensor electrical connector waterproof auto plug connector 6

ky 4 pin vw male mapsensor electrical connector waterproof auto plug connector 7

ky 4 pin vw male mapsensor electrical connector waterproof auto plug connector 8
